"These bikes are shipped unassembled. Bikes should be assembled by an authorized bicycle retailer."
Wahoo 20 Trail is a light and tough kids' bike that's ready to roll off-road. Its sturdy aluminum frame is easy to maneuver as they weave their way down the trail, but rugged enough to handle the tough stuff. A 9-speed 1x drivetrain gives them plenty of gears for pedaling up steep trails, and disc brakes provide next-level stopping power to slow their roll or help them stop on a dime on the way back down. Perfect for riders between 45-52" tall.
Lightweight carbon fork
A durable carbon fork cuts weight for easy maneuverability, absorbs bumps in the trail for happier rides on rough terrain, and comes with a legit front fender that screams, "real mountain bike".
A durable carbon fork cuts weight for easy maneuverability, absorbs bumps in the trail for happier rides on rough terrain, and comes with a legit front fender that screams, "real mountain bike".
Dropper post compatibility
Wahoo Trail can accommodate an internally-routed 31.6mm dropper post for little rippers who want to get their saddle out of the way for extra rowdy descents.
Wahoo Trail can accommodate an internally-routed 31.6mm dropper post for little rippers who want to get their saddle out of the way for extra rowdy descents.
Kid-friendly trigger shifters
Thumb-activated shifters make it easy to find the right gear and set young riders up for success with a kid-friendly version of the shifters you find on adult bikes.
Thumb-activated shifters make it easy to find the right gear and set young riders up for success with a kid-friendly version of the shifters you find on adult bikes.
Comfortable, confident geometry
An upright hybrid-style geometry mimics the feel of an adult bikeand keeps kids confident and comfortable for days where they want to ride until dinner time.
An upright hybrid-style geometry mimics the feel of an adult bikeand keeps kids confident and comfortable for days where they want to ride until dinner time.
Specs
| Pedals | VP-225 nylon platform |
|---|---|
| Fork | Wahoo 20'' carbon, post mount disc brake, ThruSkew 5mm QR |
| Hubs | Front: Formula DC-20, alloy, 6-bolt, 100mm ThruSkew Rear: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR |
| Rims | Alloy 20'', 28h |
| Stem | Bontrager alloy, 31.8mm clamp, 6 degree, 45mm length |
| Chain | KMC X9 |
| Frame | Alpha Silver Aluminum, 20'' |
| Tires | Kenda Amrak, 30 tpi, 20x2.20'' |
| Brakes | Tektro HD-J285 hydraulic disc, short reach // Tektro HD-J285 hydraulic disc, short reach |
| Saddle | Kids' padded, integrated seatpost, Blendr light mount, 31.6x230mm |
| Crankset | ProWheel alloy, 30T narrow-wide ring, 115mm length |
| Shifters | microSHIFT Advent Quick Trigger Pro SL-M6295, 9 speed |
| Handlebars | Bontrager alloy, 31.8mm clamp, 20mm rise, 580mm width |
| Tape/Grips | Kids' grip, 110mm width |
| Bottom Bracket | Sealed cartridge, 68mm |
| Rear Derailleur | microSHIFT Advent RD-M6195S, 34-38T max cog |
| Cassette/Freewheel | microSHIFT Advent H093, 11-38, 9 speed |
| Rotors | Tektro, 6-bolt, 160mm |
| Headset | Integrated, sealed cartridge bearings |
