"These bikes are shipped unassembled. Bikes should be assembled by an authorized bicycle retailer."
Nothing is off-limits to the Embolden, a trail bike designed to conquer tricky climbs, rowdy descents, and chunky rock gardens with confidence.
Wheel Options
Available in 27.5- and 29-inch wheel size options, select the Embolden that best fits you and where you want to ride.
Trail Ready
ALUXX-grade aluminum frame, tubeless wheelset, dropper seatpost, Liv Sylvia trail saddle and a 1x drivetrain allow you to tackle new technical terrain with confidence.
Custom Tuned Suspension
The 120mm of FlexPoint Suspension have been custom tuned by women, for women to provide optimal performance for the rider and the bike’s intended use, resulting in improved traction and control.
| XS (27.5") | S (27.5") | S (29") | M (29") | L (29") | ||
|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) | 380 | 406 | 405 | 420 | 440 |
| A1 | Seat Post Insertion Depth (mm) | 145 | 170 | 220 | 235 | 255 |
| B | Seat Tube Angle | 74.0° | 74.0° | 76.0° | 76.0° | 76.0° |
| C | Top Tube Length (mm) | 565 | 580 | 565 | 585 | 605 |
| D | Head Tube Length (mm) | 95 | 100 | 105 | 115 | 125 |
| E | Head Tube Angle | 67.5° | 67.5° | 67.0° | 67.0° | 67.0° |
| F | Fork Rake (mm) | 43 | 43 | 51 | 51 | 51 |
| G | Trail (mm) | 103.6 | 103.6 | 105.3 | 105.3 | 105.3 |
| H | Wheelbase (mm) | 1109 | 1125 | 1147 | 1169 | 1190 |
| I | Chain Stay Length (mm) | 435 | 435 | 438 | 438 | 438 |
| J | Bottom Bracket Drop (mm) | 20 | 20 | 40 | 40 | 40 |
| K | Stack (mm) | 560 | 565 | 614 | 623 | 632 |
| L | Reach (mm) | 404 | 418 | 412 | 430 | 447 |
| M | Stand Over Height (mm) | 690 | 705 | 712 | 734 | 755 |
| N | Handlebar Width (mm) | 750 | 750 | 740 | 760 | 780 |
| O | Stem Length (mm) | 40 | 40 | 40 | 50 | 50 |
| P | Crank Length (mm) | 165 | 170 | 170 | 170 | 170 |
| Q | Wheel Size | 27.5" | 27.5" | 29" | 29" | 29" |
