“These bikes are shipped unassembled. Bikes should be assembled by an authorized bicycle retailer.”
Fuel+ EX 5 is a smooth and capable e-MTB built to take on any trail, any time. Its Alpha NEXT Platinum aluminum frame is powered by a compact TQ HPR-60 motor that delivers a quiet, natural-feeling boost, while the RockShox fork and X-Fusion shock (145mm rear, 150mm front) soak up the bumps for confident handling. A Shimano Deore drivetrain offers a wide gear range for tackling climbs, and Shimano M4100 4-piston hydraulic brakes provide dependable stopping power.
- TQ-HPR60 300W drive unit.
- 60 Nm of torque.
- TQ 580Wh battery.
- TQ LED color display with Bluetooth and ANT+ connectivity.
| Gender | Unisex |
|---|---|
| Frame Material | Aluminum |
| Wheel Size | 29 inches |
| Battery | TQ 580Wh |
| Battery Capacity | 580 Wh |
| Brake Levers | Shimano MT4100 |
| Brakes | Shimano 4-piston hydraulic disc, MT420 caliper | Shimano RT64, centerlock, 203mm rotors |
| Chain | Shimano Deore M6100, 12 speed |
| Brake Type | Disc |
| Recommended Use | Trail |
| Suspension | Full suspension |
| Fork Travel | 140mm - 150mm |
| Charger | TQ 4A |
| Crankset | E*Thirteen Helix Core Steel 32t steel, 55mm chainline | E*thirteen E*spec Plus, 160mm length |
| Display Unit | TQ LED display with Bluetooth & ANT+ connectivity |
| Drive Unit | TQ-HPR60, 60Nm |
| Drive Unit Power/Torque | 300 watt maximum continuous rated power, 350 watt peak power |
| Fork | Rockshox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 offset, Boost110, 15mm Maxle Stealth, 150mm travel |
| Frame | Alpha NEXT Platinum aluminium, removable battery, angle-adjust headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker links, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel 145mm-160mm |
| Handlebars | Bontrager Comp, alloy, 31.8mm, 40mm rise, 780mm width |
| Max Assisted Speed | 32 km/h |
| Cassette | Shimano Deore M6100, 10-51, 12 speed |
| Rear Derailleur | Shimano Deore M6100, long cage |
| Rear Shock | X-Fusion Pro 2, 2-position damper, 205mm x 60mm |
| Rims/Wheels | Bontrager Line TLR 30, Tubeless Ready, Presta valve |
| Saddle | Bontrager Verse Short, stainless steel rails |
| Seatpost | TranzX JD-YSI34, internal routing, 34.9mm |
| Shifters | Shimano Deore M6100, 12 speed |
| Stem | Bontrager Comp, 31.8mm, 7 degree, 35mm length |
| Tape/Grips | Trek Line Comp, lock-on |
| Tires | Bontrager Gunnison Elite XC Tubeless ready, 29x2.4" |
| Groupset | Deore |
| Brand | TREK |
