"These bikes are shipped unassembled. Bikes should be assembled by an authorized bicycle retailer."
Get more rides in and make the most of every minute of the lightweight Fluid VLT C2 140. Featuring the next-level Bosch Performance Line SX drive system, and 140mm of precision-tuned suspension, integrating mixed wheels across all 5 frame sizes for optimum weight balance & handling.
DETAILS:
The latest in integrated e‑MTB technology from Bosch.
Built to Accommodate Rider Preference.
Bosch Performance Line SX with 400Wh battery.
Control your assist and range with the Bosch eBike Flow App
Reactive, playful, ride performance.
Uncompromising components engineered and spec'd for light weight capability.
Set up like a Pro – features the Ride Aligned™ Setup Guide.
No Other Way Limited Lifetime Warranty.
Frameset
| FORK | RockShox Lyrik, 29”, 150 mm Travel (Fox 36 Rhythm shown in photos) |
| REAR SHOCK | Fox FLOAT X2 Performance Elite, 185x55mm Trunnion |
Drivetrain
| REAR SHIFTER | SRAM Pod Ultimate Controller |
| REAR DERAILLEUR | SRAM GX Eagle AXS T-Type |
| CRANKSET | Praxis Alloy HD eMTB, 165mm |
| CASSETTE | SRAM 1275 T-Type 10-52T |
| CHAIN | SRAM GX Eagle T-Type |
Brakes
| FRONT BRAKE | TRP Trail Evo, 4 Piston |
| FRONT BRAKE ROTOR | TRP TR203, 203mm, 2.3mm Thick |
| REAR BRAKE | TRP Trail Evo, 4 Piston |
| REAR BRAKE ROTOR | TRP TR180, 180mm, 2.3mm Thick |
| BRAKE LEVERS | TRP Trail Evo |
Components
| HANDLEBAR | 6061 DB Alloy, 800mm, 25mm Rise |
| STEM | Norco SL 6061 Alloy 40mm Length, 35mm Clamp |
| SEATPOST | TranzX YSI08FL RAD+ Travel Adjust Dropper, 125mm (S1), 150mm (S2), 170mm (S3), 200mm (S4, S5) |
| HEADSET | FSA No. 57 ZS, Carbon Top Cover |
| HEADSET SPACER | Carbon, 2x10mm, 1x5mm |
| SADDLE | Fizik Ridon |
| GRIPS | WTB Wavelength |
Wheels
| FRONT HUB | Bear Pawls, 110x15mm Boost, 6-Bolt |
| REAR HUB | Bear Pawls, Impel 24T, 3-Bearing Steel Driver Body, 148x12mm Boost, 6-Bolt, XD |
| RIMS | WTB KOM Trail 32H, 27.5" Rear, 29" Front, 30mm ID |
| FRONT TIRE | Continental Kryptotal 29" x 2.4" Trail |
| REAR TIRE | Continental Xynotal 27.5" x 2.4" Trail |
Electric Components
| DRIVE UNIT | Bosch Performance Line SX |
| BATTERY | Bosch CPT 400Wh |
Weight
| WEIGHT | 19.9 kg (44.0 lbs) |
| WEIGHT SIZE | S3 |
| NOTE | Average of the two: green 43.88 lbs and purple 44.04 lbs |
Geometry
| 1 | 2 | 3 | 4 | 5 | ||
|---|---|---|---|---|---|---|
| Wheel Size | 29"/27.5" | 29"/27.5" | 29"/27.5" | 29"/27.5" | 29"/27.5" | |
| Travel (mm front/mm rear) |
150/140
|
|||||
| Reach | 422.5 | 447.5 | 472.5 | 497.5 | 522.5 | |
| Stack | 610 | 619 | 628 | 637 | 646 | |
| HTA | Head Tube Angle |
64.5
|
||||
| OS | Fork Offset |
44
|
||||
| ST | Seat Tube Length | 385 | 395 | 415 | 445 | 475 |
| STA | Effective Seat Tube Angle | 76.50 | 76.75 | 77.00 | 77.25 | 77.50 |
| RC | Rear Centre Length |
432
|
436 | 440 | 444 | |
| BB | Bottom Bracket Drop |
28/8
|
||||
| BBH | Bottom Bracket Height |
350
|
||||
| HTT | Horizontal Top Tube | 569 | 593 | 618 | 642 | 666 |
| WB | Wheelbase | 1181 | 1210 | 1243 | 1277 | 1310 |
| SOH | Standover | 715 | 701 | 703 | 720 | 743 |
| HT | Head Tube Length | 100 | 110 | 120 | 130 | 140 |
| Trail |
132
|
|||||
| Recommended Seatpost Drop | 125 | 150 | 170 |
200
|
||
| Maximum Post Insertion | 240 | 250 | 270 | 300 | 330 | |
| Stem Length |
40
|
|||||
| Crank Length |
165
|
|||||
| Tire Size |
2.35" – 2.6"
|
|||||
| Water Bottle Compatible | 1 x 620 mL |
1 x 750 mL
|
||||
